ASI 120 MM/MC-S or ASI 224 ?

sweiller

Hi all,

I would like to see some comparo between those cameras : ASI 120MM-S or MC-S and ASI 224 in order to decide if I keep the 120s or it is a better choice to upgrade for the 224 ?

(Note that I also have a 174MM)

Possible fields involved :

planetary (color)

Lunar (color & BW)

Solar H-alpha details (BW)

DSOs (color)

BTW this is my first trial with the 120MC and m42 with "rubber bands attached*" Nikkor 300 mm FD 2.8 @ 2.8 on unguided LXD75

Darks subtracted (5x) within FireCapture 2.5.02

~~http://sweiller.free.fr/DSO/OrionASI120MC_80poses20sObj300mm28Gam'8_wx.jpg'\>~~

No visible amp-glow I guess ...

* some better solution in on the way !

Sam@ZWO

224 is the best color planetary imaging camera so far

we will try to provide a indoor comparion one day

sweiller

Hi Sam,

Thanks !

I would like to know more about the 224 : FPS possibilities in function of ROI at all available bit dynamics.

What is the FPS in 8 bits with a small size ROI (like 192 pixels in height) ?

Nothing about this on the camera site ..

BR

Sylvain

Sam@ZWO

here is a speed we tested

10bit ADC / 12bit ADC

1304×976 150fps / 64fps

1280×960 152.4fps / 65fps

800×600 241.2fps / 102.9fps

640×480 299.4fps / 127.6fps

320×240 577.9fps / 256.4fps

sweiller

Speed can go further than 1000 FPS with a small section (about 100 pixel high, width can be large)...

sweiller

Hi,

Latest image :

Orion M42

ASI 224MC

http://sweiller.free.fr/ZWO_ASI224-MC/ASI224-MC.htm

BR
